DESIGN OF A PROGRAMMABLE LOW POWER LOW DROP-OUT REGULATOR

Jayanthi Vanama and G.L.Sampoorna

Trainee Engineer, Powerwave Technologies Pvt. Ltd., R&D India

Intern, CONEXANT Systems Pvt. Ltd.

ABSTRACT

A low power programmable low drop-out regulator capable of providing 1V output has been proposed. The regulator requires a supply voltage of 1.2V and works in the temperature range of -40 to 125 ˚C in nominal corner (i.e, normal doping for PMOS and NMOS Field Effect Transistors), yielding a load regulation of 3%. The output voltage level is controlled externally by means of 2 1-bit control signals. The circuit provides a DC gain of 30 dB and a maximum DC Power Supply Rejection Ratio of -35 dB and a worst case PSRR of -20 dB. Power dissipation in the load is nearly 100 µW.

KEYWORDS

Low Drop-Out, Voltage Regulator, Low Power, Low quiescent current.

Orginal Sourcr URL: http://aircconline.com/vlsics/V4N3/4313vlsics09.pdf

http://airccse.org/journal/vlsi/vol4.html

A RAIL-TO-RAIL HIGH SPEED CLASS-AB CMOS BUFFER WITH LOW POWER AND ENHANCED SLEW RATE

Sadhana Sharma¹ , Abhay Vidyarthi² and Shyam Akashe³

¹Research Scholar of ITM University, Gwalior, India ²Associate Professor, Dept. of ECE, ITM University, Gwalior, India ³Associate Professor, Dept. of ECE, ITM University, Gwalior, India

ABSTRACT

A rail-to-rail class-AB CMOS buffer is proposed in this paper to drive large capacitive loads. A new technique is used to reduce the leakage power of class-AB CMOS buffer circuits without affecting dynamic power dissipation .The name of applied technique is LECTOR, which gives the high speed buffer with the reduced low power dissipation (1.05%) and reduced area (2.8%). The proposed buffer is simulated at 45nm CMOS technology and the circuit is operated at 3V supply with cadence software. This analog circuit is performed with extremely low leakage current as well as high current driving capability for the large input voltages. The proposed paper is achieved very high speed with very low propagation delay range i.e.(292×10-12). So the delay of the circuit is reduced to 10%. The settling time of this circuit is reduced by 24% (in ns) at 3V square wave input. The measured quiescent current is 41µA.

KEYWORDS

CMOS buffer, Class-AB, Rail-to-rail, Quiescent current, Lector technique.

Orginal Source URL: http://aircconline.com/vlsics/V4N3/4313vlsics08.pdf

http://airccse.org/journal/vlsi/vol4.html
